Digital Mammography System for Breast Disease Examination with DR Technology
SKU: UMY-XM-050
Brand: Umy
MOQ: 1
Origin: China
Quick Info.
- SKU NO.: UMY-XM-050
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Aluminum and magnesium alloys
- After-Sale Service: Online Technical Support
- Production Capacity: 5000 Sets/Year
The digital mammography system with DR (Digital Radiography) technology is designed for precise breast disease examinations, offering high-resolution imaging to aid in early detection and diagnosis. This advanced system provides enhanced clarity and accuracy, making it a vital tool for breast cancer screenings and routine mammograms. With optimized imaging parameters, it minimizes radiation exposure while ensuring diagnostic effectiveness. Ideal for hospitals and imaging centers focused on women’s health, this system supports high-quality patient care.
The Specific Parameters
ITEMS | PARAMETERS |
---|---|
Power Output | 5kW |
Radiography Current | 10-200mA |
Radiography Voltage | 20kV-50kV |
mAs | 0.5-600mAs |
Exposure Time | 5-10000ms |
Focus Size | 0.1 / 0.3 |
Detector Type | Flat Panel Detector |
Vision Size | 10″ × 12″ |
A/D Conversion | 16 bits |
Spatial Resolution | 6 lp/mm |
Pixel Size | 2762 × 3308 |
