Trolley-Based 3D/4D Color Doppler Ultrasound Diagnostic System
SKU: UMY-US-050
Brand: Umy
MOQ: 1
Origin: China
Quick Info.
- SKU NO.: UMY-US-050
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 1000 Sets/Year
This trolley-based color Doppler ultrasound system provides advanced 3D and 4D imaging capabilities, supporting comprehensive diagnostic applications in obstetrics, cardiology, and general imaging. Designed for ease of mobility within clinical settings, it offers high-resolution imaging with detailed color Doppler visualization of blood flow and internal structures. The robust design and versatile functionality make it ideal for hospitals and diagnostic centers, enhancing workflow and patient care. This ultrasound machine is essential for accurate, real-time imaging in a range of medical specialties.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Product Overview | |
| Product Name | Full Digital Ultrasound Diagnostic System |
| Structure Type | Cart-based |
| Applications | Abdomen, obstetrics, gynecology, heart, urinary system, small organs, superficial, vascular, pediatric physical examination, and other aspects |
| Main Specifications and System Overview | |
| Operating System | ARM chip architecture, stable, concise, and powerful |
| Probe Sockets | Three active probe sockets |
| Display Mode | B, B+B, B+M, M, 4B |
| Screen | 15-inch, 1024×768 high-definition LCD |
| System Language | Chinese, English, Spanish, French |
| Machine Size | 579.1 × 710.69 × 1220.33mm |
| Net Weight | 46kg |
| Probe Options | |
| Convex Probe (C3-2) | Central frequency: 3.5MHz, multi-frequency: 2.0MHz/2.5MHz/3.5MHz/5.0MHz (depth adjustment: ≥19 levels, range: 50-280mm) |
| Linear Probe (L3-2) | Central frequency: 7.5MHz, multi-frequency: 6.5MHz/7.5MHz/8.5MHz/9.0MHz (depth adjustment: ≥6 levels, range: 50-100mm) |
| Trans-vaginal Probe (EC1-2) | Central frequency: 6.5MHz, multi-frequency: 4.0MHz/5.0MHz/6.5MHz/8.0MHz (depth adjustment: ≥6 levels, range: 50-100mm) |
| 2D Mode Specifications | |
| Gain | 0-100, step 1 adjustable visually |
| TGC | 8-segment adjustable |
| Dynamic Range | 0-120dB |
| Scanning Angle | 80-100 |
| Focus | Adjustable position, 4 focus points |
| Frame Correlation | 4-100 |
| Speckle Suppression | 0-50 |
| Power | 40-100, step 4 |
| Magnification | 1-16 |
| Grayscale Mapping | 1-19 |
| Body Mark | ≥109 types, support body position indicator |
| Pseudo-color | 28 kinds |
| Other Features | Gravel positioning function, real-time measurement data, image flip (up/down, left/right, black/white) |
| M-mode Scan Speed | 1-63 |
| Time Settings | Date, time, format adjustable |
| Image Save Format | BMP |
| Cine Loop | 256 frames |
| Measurement and Analysis Functions | |
| General Measurements | Distance, perimeter (ellipse/track), area (ellipse/track) |
| Specialist Measurements | Volume, angle, distance stenosis ratio, area stenosis ratio |
| Graphic Management System | |
| Storage Picture Save Format | BMP |
| Movie Playback | ≥256 frames |
| Report Export | U-disk supported |
| Ports | |
| VGA | 1 |
| Video | 1 |
| USB | 2 |
| Configurations | |
| Cart-Based Host | 1 unit |
| Probe Options | C3-2 convex, L3-2 linear, EC1-2 trans-vaginal |
| Optional Accessories | Thermal Printer (SONY UP-X898MD) |
